Pneumatically actuated test socket for shock-proof plugs.
The test socket is suitable for safety and function tests.
With contacts open, the plug can be inserted with minimal effort.
PE conductor testing is performed using two “jaws” insulated from each other.
This allows a 4-wire measurement to be performed. Housing made of insulating plastic.
W=120. D=80. H=75 mm
T E C H N I C A L D A T A :
Test voltage AC: max. 3000 V
Test voltage DC: max. 3500 V
PE conductor test current: max. 30 A AC
Function test current: max. 16 A AC
