The control and parameterization is done via the
built-in Ethernet interface.
Optional are the connections for the new
ELABO remote control (15 - pin D-SUB,
female) and the digital interface (25-
pole D-SUB, female).
The interfaces and the power connection are on
the lower side accessible.
The mains connection is as GST 18 built-in
connector executed.
Including ELABO extension module DIO
4 digital inputs and 6 digital outputs
Additional 4 digital inputs:
- Start
- Stop
- Remote
- Reserve
6 digital outputs:
- Faulty test object
- Test running
- Test OK
- Pulse (250ms) to open a pneum.
test cover
- System error
- Control ext. discharge relay
Dimensions:
Width = 214 mm (42TE)
Depth = 240 mm
Height = 220 mm
Technical modifications and errors excepted.
Optionally available with calibration.
