ELABO Insulation Tester for mounting in a Control cubicle
Please note that the price shown does not include packing and shipping.
These additional costs will be calculated at checkout in relation to size, weight and shipping address.
Also, please note that delivery times are between 16 and 18 weeks.
ELABO PE-Conductor Tester for mounting in a Control cubicle.
Test voltage 6 / 12V AC
Test current 2 ... 40 A manually adjustable
Measuring ranges:
5 ... 1200 mOhm
The connections (feedthrough terminal) are on the front panel.
The control and parameterization is done via the
built-in Ethernet interface.
Optional are the connections for the new
ELABO remote control (15 - pin D-SUB,
female) and the digital interface (25-
pole D-SUB, female).
The interfaces and the power connection are on
the lower side accessible.
The mains connection is as GST 18 built-in
connector executed.
Inclusive ELABO calibration certificate
TECHNICAL SPECIFICATIONS:
AC power supply:
230V, 50Hz / 60Hz +24 Vdc external (DIO, RC)
Open circuit voltage:
6 / 12V AC
Test current:
2 ... 40A manually adjustable
Output power:
max. 480W
Measuring range:
5 ... 1200 mOhm
Monitoring:
R_max, I_min and U_max
Adjustable test time:
0.5 s ... 1d adjustable in 0.1s increments
Power-on time:
50%, max. 60 sec.
Display of measured values, deviations,
Accuracy:
Test current:
Display resolution:
2.00A ... 40.00A: 0.1A
Measuring accuracy:
± 1%, ± 20 digits
Test voltage:
Display resolution:
50mV ... 12V: 10mV
Measuring accuracy:
± 10 digits
Resistance:
Display resolution:
5mOhm ... 1,2Ohm: 10mOhm
Measuring accuracy:
± 30 digits
Including ELABO extension module DIO
4 digital inputs and 6 digital outputs
Additional 4 digital inputs:
- Start
- Stop
- Remote
- Reserve
6 digital outputs:
- Faulty test object
- Test running
- Test OK
- Pulse (250ms) to open a pneum. test cover
- System error
- Control ext. discharge relay
Dimensions:
Width = 214 mm (42TE)
Depth = 240 mm
Height = 220 mm
Technical modifications and errors excepted.
Optionally available with calibration.
