ELABO BestPerformance PE/IS/HVAC Combitester equipped with a switching unit and a touch LC display.

Drawer module 19" / 4 HE

The device is equipped with an electronic
high voltage source.

For the adaptation of test equipment plugs for
the following units are implemented on the rear:
- PE test probe
- HV test probe (1)
- 7pole system plug

System-Interfaces:
Ethernet (alternative RS232C or USB)

Digital-Interface:
Inputs:
- Start, Stop Remote
Outputs:
- OK, I>Imax, System failure, HV On,

Technical data:

Test voltage: 0,1..2,5/0,2..5 kV AC Voltage programmable
Floating output
Tripping current 0 .. 10/100mA AC
Measuring accuracy:
Voltage measurement: 1% of rdg. ± 3 digit
Resolution voltage measurement: 10 V

current measurement (apparent /active c.):
100 mA - range: 1 % of rdg. ± 3 digit
10 mA - range: 1 % of rdg. ± 3 digit

Resolution current measurement:
100 mA - range: 100 uA
10 mA - range: 10 uA
Programmable test time: 0,5 .. 999,9 s

PE conductor measurement
- Open-circuit voltage: 6 V / 12 V
- Test current: 10 ... 32 A
- Resistance measuring range: 0 .. 1,2 Ohm
- Resolution resistance measurement: 1 mOhm
- Voltage drop measuring range: 0 .. 12 V
- Resolution voltage measurement: 10 mV
- Measurement range current measurement: 0..50 A
- Resolution current measurement: 100 mA
- Four-wire method
- Accuracy: 1,5% of rdg. ± 3 digit
- Programmable test time: 0,5 .. 999,9 s

Insulation resistance measurement
Test voltage: 50 .. 1200 VDC
Measurement ranges: 0,1 .. 10/100/1000 MOhm

Resolution resistance measurement:
10,0 MOhm range: 100 kOhm
100 MOhm - range: 1 MOhm
1,00 GOhm range: 10 MOhm

Accuracy: 1% of rdg. ± 3 digit
Programmable test time: 0,5 .. 999,9 s
Programmable down time: 0,5 .. 99,9 s

Display / Operating unit:
4,3" LC touch display; single colour
Interface: Ethernet (Alternative RS232C or USB)
Test run : fully automatic / manually
AC power supply: 230V ± 10% / 49 .. 61Hz

Incl. ELABO-Calibration-Certificate.

Weight: appr. 24 kg

W = 483 mm; H = 177 mm; D = 360 mm
