ELABO HighPerformance High Voltage Tester with control unit and touch display.

Module 19" / 4 HE
The device is equipped with an electronic high
voltage source. Because of the modular design
many expansions can be integrated.

System-Interfaces:
RS 232-C (optional Ethernet or USB)

Digital-Interface:
Inputs:
Start, Stop Remote
Outputs:
OK, I>Imax, System failure, HV On,

T e c h n i c a l d a t a s :

Test voltage: 0,1..2,5 / 0,2..5 kV AC
Voltage programmable
Floating output
Tripping current 0..1/10/100mA AC

Measuring accuracy:
Voltage: 0,5% of rdg. ± 2 digit
apparent current:
100 mA - range: 0,5 % of rdg. ± 2 digit
10 mA - range: 0,5 % of rdg. ± 5 digit
1 mA - range: 0,5 % of rdg. ± 20 digit
- peak current:
100 mA - range: 1,0 % of rdg. ± 5 digit
10 mA - range: 1,0 % of rdg. ± 5 digit
1 mA - range: 1,0 % of rdg. ± 20 digit
- active current:
100 mA - range: 1,0 % of rdg. ± 8 digit
10 mA - range: 1,0 % of rdg. ± 8 digit
1 mA - range: 1,0 % of rdg. ± 20 digit

Display / Operating unit:
6,5" TFT touch display; colour
Interface: RS232C (Optional Ethernet or USB)
Test run : fully automatic / manually
AC power supply: 230V ± 10% / 50Hz

Incl. ELABO-Calibration-Certificate.

Weight: appr. 22kg

B = 483 mm; H = 177 mm; T = 360 mm
