ELABO HighPerformance High Voltage Tester with control unit and touch display.
Module 19" / 4 HE The device is equipped with an electronic high voltage source. Because of the modular design many expansions can be integrated.
System-Interfaces: RS 232-C (optional Ethernet or USB)
Digital-Interface: Inputs: Start, Stop Remote Outputs: OK, I>Imax, System failure, HV On,
T e c h n i c a l d a t a s :
Test voltage:
0,1..2,5 / 0,2..5 kV AC Voltage programmable Floating output Tripping current 0..1/10/100mA AC
Measuring accuracy: Voltage:
0,5% of rdg. ± 2 digit apparent current: 100 mA - range:
0,5 % of rdg. ± 2 digit 10 mA - range:
0,5 % of rdg. ± 5 digit 1 mA - range:
0,5 % of rdg. ± 20 digit - peak current: 100 mA - range:
1,0 % of rdg. ± 5 digit 10 mA - range:
1,0 % of rdg. ± 5 digit 1 mA - range:
1,0 % of rdg. ± 20 digit - active current: 100 mA - range:
1,0 % of rdg. ± 8 digit 10 mA - range:
1,0 % of rdg. ± 8 digit 1 mA - range:
1,0 % of rdg. ± 20 digit
Display / Operating unit: 6,5" TFT touch display; colour Interface: RS232C (Optional Ethernet or USB) Test run : fully automatic / manually AC power supply: 230V ± 10% / 50Hz
