ELABO BestPerformance High Voltage Tester AC equipped with touch LC display.
Drawer module 19" / 4 HU The device is equipped with an electronic high voltage source. The floating output of test voltage is provided to two high voltage plugs on front and rear panel, each.
System-Interfaces: Ethernet (alternative RS232C or USB)
Digital-Interface: Inputs: - Start, Stop Remote Outputs: - OK, I>Imax, System failure, HV On,
Technical datas:
Test voltage:
0,1..2,5/0,2..5 kV AC Voltage programmable Floating output Tripping current 0 .. 10/100mA AC Measuring accuracy: Voltage measurement:
1% of rdg. ± 3 digit Resolution voltage measurement:
10 V current measurement (apparent /active c.): 100,0 mA - range:
1 % of rdg. ± 3 digit 10,00 mA - range:
1 % of rdg. ± 3 digit Resolution current measurement: 100,0 mA - range:
100 uA 10,00 mA - range:
10 uA
Display / Operating unit:
4,3" LC touch display; single colour Interface:
Ethernet (Alternative RS232C or USB) Test run :
fully automatic / manually AC power supply:
230V ± 10% / 50 Hz
