Please note that the price shown does not include packing and shipping.
These additional costs will be calculated at checkout in relation to size, weight and shipping address.
Also, please note that delivery times are between 16 and 18 weeks.

ELABO-Precision High-Voltage Multimeter with digital display

The SM-MEAS-0 table measuring device
("High Voltage Meter") is for measuring
High voltages and occurring load currents
at high voltage generators. The
preferred application is for the adjustment and
the calibration of high voltage testers /
- generators or others
High voltage applications up to a voltage
by max. 10 kVrms and a current of 500 mArms.

Interface:
Ethernet interface

Technical specifications

AC power supply: 100V ... 230V ~, 50Hz / 60Hz
Measuring voltage: ± 1 V ... ± 10 kV (DC)
Measuring voltage: 2 V ... 7 kVrms (AC)
Measuring range voltage: 10 kV
Measuring current: ± 0.05 mA ... ± 500 mA
Measuring ranges current: 1/10/100/500 mA

High-voltage connections:
2x Topas connection cable plug 1.8m (front)
2x Topas panel sockets (rear panel)
U_max. 7 kVrms (AC), continuous operation

Dimensions:
Width = 260mm
Depth = 260mm
Height = 160mm

Technical modifications and errors excepted.

Optionally available with calibration
