ELABO Insulation Tester for mounting in a Control cubicle

Please note that the price shown does not include packing and shipping.
These additional costs will be calculated at checkout in relation to size, weight and shipping address.
Also, please note that delivery times are between 16 and 18 weeks.

ELABO high voltage test module for mounting in a Control cubicle.

Test voltage: 50 ... 3000V DC
Test current: 0.03 ... 10mA
Current measuring range: 30µA ... 10mA
Resistance measuring range: 10kOhm ... 5GOhm

The control and parameterization is done via the
built-in Ethernet interface.
Optional are the connections for the new
ELABO remote control (15 - pin D-SUB, female) and the digital interface (25-pole D-SUB, female).

The interfaces and the power connection are on
the lower side accessible.
The mains connection is as GST 18 built-in
connector executed.

Inclusive ELABO calibration certificate

T E C H N I C A L S P E C I F I C A T I O N S :

AC power supply: 100V - 240V, 50Hz / 60Hz +24 Vdc external (DIO, RC)
Test voltage: 0,05kV ... 3,00kV, variable adjustable in 1V increments
Output power: max. 30W
Measuring range: 10kOhm ... 5GOhm
Monitoring: I min and I max (contact monitoring) R_min and R_max (contact monitoring)
Adjustable test time: 0.5 s ... 1d adjustable in 0.1s increments

Automatic range selection or fixed
Measuring range after worst-case analysis

Display of measured values, deviations,
Accuracy:
Voltage:
Display resolution: 0,05kV ... 3,00kV: 0,01kV
Measuring accuracy: up to 3kV: ± 0.2%, ± 2Digit

Including ELABO extension module DIO
4 digital inputs and 6 digital outputs

Additional 4 digital inputs:
- Start
- Stop
- Remote
- Reserve

6 digital outputs:
- Faulty test object
- Test running
- Test OK
- Pulse (250ms) to open a pneum. test cover
- System error
- Control ext. discharge relay

Dimensions:
Width = 214 mm (42TE)
Depth = 310 mm (including plug)
Height = 220 mm

Technical modifications and errors excepted.

Optionally available with calibration.
