ELABO high voltage test module for mounting in a Control cubicle.
Test voltage:
100 ... 10000V DC Test current:
0.01 ... 3mA
Current measuring range:
10µA ... 3mA
Resistance measuring range:
30kOhm ... 5GOhm
The control and parameterization is done via the built-in Ethernet interface. Optional are the connections for the new ELABO remote control (15 - pin D-SUB, female) and the digital interface (25- pole D-SUB, female).
The interfaces and the power connection are on the lower side accessible. The mains connection is as GST 18 built-in connector executed.
Inclusive ELABO calibration certificate
TECHNICAL SPECIFICATIONS:
AC power supply:
100V - 240V, 50Hz / 60Hz +24 Vdc external (DIO, RC) Test voltage:
0,1kV ... 10,00kV, variable adjustable in 1V increments Output power:
max. 30W Measuring range:
30kOhm ... 5GOhm Monitoring: I min and I max (contact monitoring) R_min and R_max (contact monitoring)
Adjustable test time:
0.5 s ... 1d adjustable in 0.1s increments Automatic range selection or fixed Measuring range after worst-case analysis
Display of measured values, deviations, Accuracy: Voltage: Display resolution:
0,02kV ... 10kV: 0,01kV Measuring accuracy:
up to 10kV: ± 0.2%, ± 2Digit
Including ELABO extension module DIO 4 digital inputs and 6 digital outputs
6 digital outputs: - Faulty test object - Test running - Test OK - Pulse (250ms) to open a pneum. test cover - System error - Control ext. discharge relay
Dimensions: Width = 214 mm (42TE) Depth = 310 mm (including plug) Height = 220 mm
