ELABO BestPerformance PE/IS/HVAC, 1~ Functiontest Combitester equipped with a switching unit and a touch LC display
+4
+3
+2

ELABO BestPerformance PE/IS/HVAC, 1~ Functiontest Combitester equipped with a switching unit and a touch LC display

Back to catalog
0,00 EURO
Price incl. VAT (19%) 0,00 EURO
Excl.  shipping
ELABO BestPerformancePlus Kombitester PE/IS/HVAC
In stock
Product Details
Lieferzeit: 8-10 weeks

ELABO BestPerformance PE/IS/HVAC, 1~ Functiontest

Combitester equipped with a switching unit and a touch LC display

"Drawer module 19"" / 8 HE"
The device is equipped with an electronic high voltage source.
For the adaptation of test equipment plugs for the following units are implemented on the rear:
- PE test probe
- HV test probe (1)
- Warning lamp
System-Interfaces:
Ethernet
Digital-Interface:
Inputs:
- Start, Stop Remote
Outputs:
- OK, I>Imax, System failure, HV On,
Technical datas:
High voltage test
- Test voltage: 0.1 ... 2.5/0.2 ... 5 kV AC
- Voltage programmable
- Floating output
- Tripping current 0 .. 10/100mA AC
- Measuring accuracy:
- Voltage measurement: 1% of rdg. ± 3 digit
- Resolution voltage measurement: 10 V
- current measurement (apparent /active c.):
100 mA - range: 1 % of rdg. ± 3 digit
10 mA - range: 1 % of rdg. ± 3 digit
- Resolution current measurement:
100 mA - range: 100 uA
10 mA - range: 10 uA
- Programmable test time: 0.5 ... 999.9 s
PE conductor test
- Open-circuit voltage: 6 V / 12 V
- Test current: 5 ... 32 A
- Resistance measuring range: 0.001 ... 1.2 Ohm
- Resolution resistance measurement: 1 mOhm
- Voltage drop measuring range: 0 ... 12.00 V
- Resolution voltage measurement: 10 mV
- Measurement range current measurement: 0...32 A
- Resolution current measurement: 100 mA
- Four-wire method
- Accuracy: 1.5% of rdg. ± 3 digit
- Programmable test time: 0.5 .. 999.9 s
Insulation resistance test
- Test voltage: 50 ... 1200 VDC
- Measurement ranges: 0.1 ... 10/100/1000 MOhm
- Resolution resistance measurement:
10,0 MOhm range: 100 kOhm
100 MOhm - range: 1 MOhm
1,00 GOhm range: 10 MOhm
- Accuracy: 1% of rdg. ± 3 digit
- Programmable test time: 0.5 .. 999.9 s
- Programmable down time: 0.5 .. 99.9 s
1~ Funtion test
- External power supply connector C20
- Automatic circuit-breaker dual-pole B 16 A
- Voltage measurement range: 50 ... 300 V (AC)
- Resolution voltage measurement: 0.1 V
- Accuracy: 1% of rdg. ± 1 digit
- Current measurement range: 0.1 ... 16 A (AC)
- Resolution current measurement: 0.01 A
- Accuracy: 1% of rdg. ± 5 digit
- Active power measurement range: 20 ... 4000 W
- Resolution active power measurement: 1 W
- Accuracy: 1.5% of rdg. ± 5 digit
- Apparent power measurement range: 20 ... 4000 VA
- Resolution apparent power measurement: 1 VA
- Accuracy: 2% of rdg. ± 5 digit
Continuity test
- Voltage: 24 V (AC)
- Measurement range: 5 ... 1000 Ohm
- Resolution continuity test: 1 Ohm
- Accuracy: 2.5% of rdg. ± 1 digit
- Power max.: 50VA
Display / Operating unit:
"4,3"" LC touch display; single colour"
Interface: Ethernet
Test run : fully automatic / manually
AC power supply: 230V ± 10% / 49 ... 61Hz
Weight: appr. 35 kg
W = 483 mm; H = 355 mm; D = 360 mm
