ELABO-Ableitstrommessgerät 1~ mit automatisch geregelter Versorgung, erdfrei

0,00 EURO
Sold out
Price incl. VAT (19%) 0,00 EURO
Excl.  shipping
Product Details
Lieferzeit: 16-18 weeks

ELABO leakage current test module for 1-phase test objects with control for supply modules without earth potential reference for operating

the test object
- Installation in switch cabinets
- Internal and external supply of the of the test object possible
- Testing according to standards in conjunction with ELUTION software + standards licenses
- Max. 2 leakage current basic measuring circuits can be integrated (options) (MD according to EN60990 B3/B4/B5, MD according to EN60601 MED B12, MD according to UL/CSA)
- Control and parameterization via the Ethernet interface and protocol
- Performance of the test in various operating operating modes and fault scenarios via Basic test steps, predefined in standards files (normal operation without error, normal operation with N error, normal operation with PE error, Reverse polarity operation without fault, reverse polarity operation with N-fault, reverse polarity operation with PE-fault)
- Variable test sequence, execution of the test (basic test steps) can be individually selected and deselectable.
- Adjustable test time and warm-up phases before carrying out the test

Front panel connections (terminal blocks):

- External power supply ( test object)
- Test object connection, 1-phase, vi1, vi2
- Additional connections for tests according to EN60601-1, MED
Connections on the underside:
- Mains connection (GST 18 built-in plug)

- external power supply 24VDC, max. 1A(fused) for digital I/O, RC, warning light (2-pin WAGO plug)

- Ethernet interface (RJ45 socket)
- Connection for warning lamp set 24VDC (M12- socket, 5-pin)
- RC remote control connection with display (15
- pin D-SUB, female)
- Digital I/O connection (25-pin D-SUB, female)
- Connections for 1-phase supply module for regulating the operating / test voltage (plug connector (3-pin) with interlock for power supply and power supply and M12 socket (8-pin) for regulating the control of the electromechanical transformer)
T E C H N I C A L D A T E S :
Supply voltages (test module):
- Mains connection, 230V AC, 1-phase, max. 2A (fused), 50/60Hz, max.
Mains voltage fluctuation ± 10 %
- External power supply 24 V DC, max. 1A (fused), (DIO, RC, warning lamp, SK)

Supply voltage / test voltage ( test object):

- Internal supply via separate supply module supply module without earth potential reference, 50V ... 280V AC, 1-phase, max. 4A (rev. fused), 50/60Hz mains-dependent
- External power supply, 50V ... 280V AC, 1-phase, max. phase, max. 15A (rev. fused), 50 ... 400Hz
Measurements during operation / testing of the device under test:
- Operating / test voltage: 10V ... 285V AC, 50Hz ... 400Hz
- Operating current: 0.1A ... 15A AC, 1-phase
Measurements Leakage current:
- 5 µA ... 10 mA DC / AC, 50Hz ... 1MHz
- 3 leakage current measuring ranges: 0.1mA / 1mA / 10mA
- Measurement types: I_trms, I_ac, I_dc, I_peak, I_mad (depending on the test standard used)
- Fixed measuring range according to I_lc_max or automatic measuring range adjustment
Monitoring:
- Operating voltage: U_op_min ≤ U_op ≤ (U_op + 10%)
- Test voltage: U_test_min ≤ U_test ≤ (U_test + 10%)
- Operating current: I_op_min ≤ I_op ≤ I_op_max
- Leakage current: I_lc_min ≤ I_lc ≤ I_lc_max (max. 2 leakage currents for tests according to standard EN60601-1, MED)

Adjustable test time and warm-up phases:

- 1s ... 1d adjustable in 0.1s steps

Setting accuracy, deviations:

- Operating / test voltage: 50V ... 280.0V ±1% of SW, ±0.5V
Measuring accuracy, deviations, display of measured values (resolution): (see data sheet)
Including ELABO expansion module Digital I/O:
- 4 digital inputs: START, STOP, REMOTE, reserve
- 6 digital outputs: test item iO, test item niO, system error, test in progress, pulse (250ms)for pneumatic test cover, ext. discharge via additional relay
Mounting:
6 holes for screwing to a mounting plate mounting plate
Dimensions:
426mm (84TE) x 220mm x 235mm (W/H/D)
Weight:
approx. 8.5kg
Subject to technical changes.
