ELABO- Protective conductor continuity and insulation testing system for electric monorail systems

Please note that the price shown does not include packing and shipping.
These additional costs will be calculated at checkout in relation to size, weight and shipping address.
Also, please note that delivery times are between 6 and 8 weeks.

ELABO- Protective conductor continuity and insulation
testing system for overhead monorail systems

Installed in
a sheet steel housing Rittal 1038600
color RAL 7035 with mounting plate to accept
of a continuity test system and ISO test system.
Protective conductor continuity test:
The system provides alternating current of max. 30A with
a no-load voltage of 12V and is used for the testing of
testing of protective conductor connections on
overhead tracks (continuity measurement).
The test current is compared with a fixed threshold value via a
a fixed threshold value.
If the measured value is above the threshold value,
a good signal is generated.
For the self-test of the PE evaluation, a
test resistor is installed. The control is
by a 24V DC signal.
Insulation resistance test:
The ISO test module is used to measure the
insulation resistance of the EHB in a de-energized condition
according to the valid VDE/IEC regulations.
The test voltage is 500V DC
(stabilized). The current is limited to max. 3mA
no further safety measures are required.
safety measures are necessary.
Via trim potentiometer the lower limit value
Rmin can be adjusted. If this value is undershot during
value is undershot during the test, an error
error message and the error output is set.
The insulation test is started together with the
with the protective conductor continuity test by
setting the SET input at the interface.
For the control an external voltage of 24V
DC is required.
Equipment:
- 5 indicator lights (in the door)
ACTIVE, PE/IS-FAULT, PE/IS-GO
- 1 SET internal button (in the door)
- 1 current transformer 30A
- 1 power transformer 400V/50Hz +/-10% !!!
- 1 comparator card for DU test
- 1 test resistor R1 (0,28Ohm)
- 1 insulation test module
test voltage: 500VDC/3mA
measuring range: 0..10/0..100MOhm
Pushbuttons, indicator lights, contactors, relays from Siemens
/ Sirius.
Terminals from Phoenix.
Warning notice as sticker on the door.
The connection is made via 5 skintop
glands on the bottom side of the
terminal box.
W = 380 mm, H = 600 mm, D = 210 mm
