94-1F.3Z803 - ELABO-Housing 3 HU /four-part.

Bitte hier für Anfrage klicken

Please note that the price shown does not include packing and shipping.
These additional costs will be calculated at checkout in relation to size, weight and shipping address.
Also, please note that delivery times are between 16 and 18 weeks.

ELABO-Housing 3 HU /four-part.

Colour grey with ventilation slots to accept a PE Conductor tester 90-2A.

For interface adjustment, one relay each for start and reset is installed in the housing.
For a short-term function test of the PE device, a measuring shunt of 0.3 Ohm/50W is connected to the input via a 24 VDC signal from the PLC.
Including complete wiring on terminal blocks.
Connection via 4 PG glands on the underside of the terminal box.

W = 355, D = 330, H = 225
